25Gbps PIN-TIA 850nm TO-CAN Series photodiode

Features:
● Data rates up to 25 Gbps.
● 850nm multimode.
● Single +3.3V Power Supply.
● -40℃ to 85℃ Operation.
● Received signal strength indicator(RSSI).
Applications:
●High speed Data Communication



  • Wavelength :

    850nm
  • Rate :

    25G

25Gbps 850nm PIN-TIA TO-CAN Series

Features:

● Data rates up to 25 Gbps.

● 850nm multimode.

● Single +3.3V Power Supply.

● -40℃ to 85℃ Operation.

● Received signal strength indicator(RSSI).

Applications:

●High speed Data Communication.

Specifications:

Absolute Maximum Ratings:

Parameter

Symbol

Min.

Max.

Unit

Optical Input Power

Pin

5

dBm

Operating Temperature

Top

-40

+85

Storage Temperature

Tstg

-40

+85

Lead Solder Temperature

260

Lead Solder Time

10

s

Characteristics:(Ta=25℃ unless otherwise noted)

Parameter

Symbol

Test Conditions

Min.

Typ.

Max.

Unit

Supply Voltage

Vcc

2.97

3.3

3.63

V

Supply Current

Icc

Vcc=3.3V

26

33

mA

Wavelength Range

λ

Vcc=3.3V

820

850

860

nm

RSSI Dark Current

Id

Vcc=3.3V

100

nA

Bandwidth

BW

-3dB

--

21

GHz

Overload

OL

Vcc=3.3V

-3

dBm



Sensitivity



Sen

25.78Gbps,PRBS31

850nm,ER=4dB,

BER= 10E- 12







-9



dBm
